s940-p Concrete Laser Screed Machine
€36,800.00
The Hiking S940-P Concrete Laser Screed is an efficient piece of equipment designed specifically for construction companies and concrete contractors. Its primary purpose is to streamline the concrete levelling process and increase construction efficiency. This machine uses advanced laser technology and a hydraulic system to quickly and accurately level large areas of concrete, ensuring that the floor is flat and smooth to the highest standards. The S940-P Concrete Laser Screed represents a significant advance over traditional methods. It reduces labour requirements by more than twofold, enabling the paving of 2,000 to 3,500 square metres per day. Its powerful 25hp engine and imported hydraulic system ensure stability and durability, making it suitable for a wide range of complex construction environments.
The S940-P Concrete Laser Screed addresses several challenges faced in traditional construction. Firstly, it uses point-to-point laser measurement, which eliminates the errors associated with manual string lines and template supports, thereby minimising variations in floor evenness. Secondly, the machine’s high-frequency vibration system (4,200 vibrations per minute) densifies the concrete, improving the overall integrity and durability of the surface. In addition, the machine’s four-wheel drive and planetary gear design allow it to manoeuvre freely in deep concrete, thus enhancing construction flexibility. For construction companies and contractors in the Philippines, the S940-P Concrete Laser Screed is an efficient tool that also offers the ideal choice for improving construction quality and reducing costs.
If you are interested in our products and want to know the specific parameters and prices, please click the button below and leave your contact information.
DESCRIPTION
Hiking Machinery dedicated to providing construction companies and contractors with high-cost-performance concrete leveling solutions through innovative technologies and superior products.The S940-P is a result of our independent research and development, integrating several advanced technologies to help you achieve higher efficiency and cost-effectiveness in your projects.
| Model | S940-P |
|---|---|
| Engine model | HONDA GX690 |
| Power | 18.4kW/ 25HP |
| Fuel | Gasoline |
| Fuel tank capacity | 19L |
| Leveling width | 2.5m |
| Tire | Inflatable narrow tires(with inflatable wide tires) |
| Exciting force | 2500N(MAX) |
| Net weight | 950kgs |
| Dimensions | 3470*2860*1620mm |
| Paving mode | Hydraulic spiral conveyor paving |
Precise Laser Measurement: Utilising point-to-point laser measurement technology, it completely eliminates errors from manual line pulling and template supports, minimising deviations in surface flatness.
High-Frequency Vibration System:The high-frequency vibration system delivers 4,200 vibrations per minute, significantly enhancing the density of the concrete and improving surface integrity and durability.
Flexible Maneuverability:The four-wheel drive and planetary gear design allow the machine to move freely in deep concrete, greatly increasing operational flexibility.
Rear Engine Design:with its 25-horsepower Honda GX690 engine, ensures stable operation in complex environments.
Imported Hydraulic System: Fully electronic control hydraulic system is user-friendly and highly precise, enhancing the machine’s stability and durability.
Multi-functional Leveling Head: The 2.8-meter wide leveling head design ensures optimal performance and better leveling results.
Leica Laser System: A high-precision laser measurement and control system eliminates the need for manual lines or templates, reducing changes in surface height to a minimum.
Electronic Joystick Control: The electronic joystick allows for easy, precise control of forward, backward, steering, and speed operations.
All-Terrain Tires: Equipped with pressure-resistant narrow tires and inflatable wide tires, suitable for various concrete leveling conditions without needing a reinforcement mesh.
The Hiking S940-P Concrete Laser Screed is set to transform the way your construction team operates, addressing flatness issues while significantly boosting efficiency and reducing labour costs. Whether for large building projects or small concrete jobs, the S940-P ensures the timely completion of high-quality work, leaving a lasting impression on your clients. By choosing the Hiking S940-P, you can be confident that you are selecting an efficient, reliable and economical construction solution.
FQA
1. Product Quality
As a world leader in the supply of construction equipment, Hiking Machinery places product quality at its core. Our equipment is manufactured in strict accordance with the ISO 9001:2016 quality management system, using high-quality components from globally recognised suppliers to ensure that each machine meets the highest standards. Before despatch, each machine undergoes systematic testing to ensure that the products you receive are impeccable. With a professional and meticulous approach, we provide you with reliable, high-quality equipment.
2. After Sales
While we strive to uphold the highest standards of product quality, unforeseen issues can occasionally arise. To address this, we offer a one-year free warranty service for our customers in Europe. Throughout this period, we will provide complimentary parts and technical support for any issues not caused by user error. For your convenience, designated spare parts will be included with your shipment.
After the one-year warranty period, we will still offer a cost guarantee service. Our engineers will be available for free technical consultations, and you will only be responsible for the cost of any necessary parts.
3. Shipping
We offer a variety of shipping methods for our European customers, including sea, rail, and air transportation. For most products, we can provide door-to-door service. Generally, shipping times are approximately 45-55 days for sea transport, 35-45 days for rail, and 20-25 days for air. Please note that these timeframes are approximate due to the uncertainties of international shipping. We will ensure that all equipment is carefully packaged to guarantee safe transportation. Hiking takes full responsibility for any damage or loss that may occur during transit to protect your interests.
